Devotion - Model WNS -Integral Gas or Oil Fire Tube Condensing Steam Boilers
DEVOTION Condensing Steam Boilers apply condenser heat recovery technology to thorough recover and reuse energy in the flue gas, as a result of which, exhausted flue temperature is remarkably lowered and thus achieve high-efficiency and low-pollution emission.
-
Payment: TT LC at sight
-
Product Origin: China
-
Color: Blue and White
-
Shipping Port: Guangzhou, Shenzhen
-
Min Order: 1
-
Lead Time:30-45 Days
- Rated evaporation: 0.5-20 t/h
- Fuel: light diesel, heavy oil, natural gas, urban gas
- Heat efficiency: ＞100%
External and separate energy saving devices and anti-corrosive condenser on the Devotion Condensing Steam Boilers can recover heats in the exhausted flue. The after-flue temperature is lowered under 70℃. Latent heat released when smoke condensates is maximally utilized, in the meanwhile, unique frequency scaling continuous water feed and proportional combustions can largely increase heat efficiency, i.e, save the fuels. In the re-utilization of energy, harmful emission can also be reduced and thus lessen impact on the environment.
- Two Stage Energy Saving. Absorb heat of exhaust flue by taking advantage of economizer and condensate vapor through finned-tube condenser to recover 5% of the afterheat and decrease exhaust flue temperature to 70℃.
- All Wetback Three Pass Structure Heat is thorough absorbed when flue goes through chamber, fire tubes, economizer. The boiler features compact configuration, packaged for delivery, fast and easy installation.
- Low Nox Combustion Big hearth specially designed to achieve super low NOx emission, together with full premix combustion technology (FPB technology ) and flue gas recirculation(FGR) technology, lower the emission of NOx below 30mg/m³.
- Corrugated furnace plus threaded fire tubes. Increase heating surface of the hearth, and avoid damages to the hearth resulted from Expansio
