ClearChart - Model 4 - Digital Acuity System

SHARE

The all-new family of ClearChart® Digital Acuity Systems from Reichert® are all-in-one, elegant, simple to use, and uniquely designed to meet all of your acuity testing needs with a wide selection of optotypes and other special test charts. The standard ClearChart 4 Digital Acuity System features a new 24 inch, high resolution, LED backlit display, is lightweight, cool running, and long-lasting. The intuitive user interface, whether controlled from the easy-to-use infrared remote or via the Phoroptor® VRx Digital Refraction System, provides the best user experience of any digital acuity chart.

Most popular related searches
mounting bracket

Catalog Number: 13795

Display: 24 in. (60 cm) LED backlit LCD (1920x1080 Pixels)

Max Illumination: 220 cd/m2

Photopic Illumination: 85 cd/m2

Mesopic Illumination: 3 cd/m2

Refraction Range: 1.83 m (6 ft) - 7.5 m (24.6 ft)

Dimensions:
Height: 39.62 cm (15.60 in)
Width: 58.92 cm (23.20 in.)
Depth: 7.62 cm (3.00 in.)

Weight: (unpacked) 5.9 kg (13.1 lbs.)

Communication:
- RS232 Serial Port
- 2 USB Ports
- Can be linked by wired or wireless connection to a Reichert® digital Phoroptor®

Remote Control: Infrared

Electrical:
Voltage: 100 - 240 volts AC 50/60 Hz
Input Power: 50-75 VA
Fuses: Time-Lag (2.5A, 250V), 5 x 20mm
Remote Control: 2 AAA (LR03) batteries

Operational Environment:
Temperature: 10° C (50° F) to 35° C (95° F)
Relative Humidity: 30% to 75%
Atmospheric Pressure: 80 (23.6 in. Hg) to 106 kPa (31.3 in. Hg)


ClearChart 4 (13795) comes with:

(1) Remote control
(2) AAA (LR03) batteries
(2) Power cords
[0.6 m (3 ft.) length and 3 m (10 ft. length]
(1) Wall mount bracket with screws
(1) Wall mount adaptor
(1) User’s Guide

Optional accessories:
(1) Wall mount bracket adaptor
(1) USB Bluetooth adapter
(1) Wireless dongle kit
(1) Pair red/green glasses

ClearChart 4 Optotypes:

Standard:
17 Letter Set
8 Letter Set
Sloan
Tumbling E
Landolt C
O Landolt C
HOTV
Numbers

Childrens:
Kolt
Children`s Shapes
Allen

Presentation:
Single Line
Double/ Same
Double/ Decreasing
Triple Same
Triple Decreasing
Quadruple Same
Quadruple Decreasing
Single Letter
Column
Column Uneven

Other:
Xcyl Crowding Dots
Astigmatic "Wheel"
T
Fixation Dot
Horizontal Disperity
Vertical Disperity
Worth 4 Dot
Crowding Bar
Suppression
Red Green Filter
