Shoals Technologies Group
Dual Certified PV Wire
The first U.S.A. manufactured solar cable to achieve TUV and UL certification, based on a versatile single-conductor design to meet the varying needs of the solar industry.
Most popular related searches
- Two low smoke halogen-free, flame retardant and sunlight resistant cross-linked compound outer layer and halogen-free thermoset polyolefin inner layer.
- Continuous operating temperature of 90°C wet or dry
- UL listed as Sunlight Resistant
- Vertical Flame Performance: EN 60332-1
- Excellent UV and Ozone resistant
- Suitable for wet, damp and humid locations
- Specially designed for excellent flexibility
- Compatible with all major connectors
- Available in Black or Red
- TUV Certification 2 Pfg 1169/08.2007
- TUV Listed as PV1-F; 1000V
- UL Listed as Type USE-2
- UL Listed as RHW-2
- UL Standard 44: Thermoset Insulated Wires & Cables, Type RHW-2
- UL Standard 854: Standard for Safety for Service Entrance Cables,
- Type USE-2; 600V
- ASTM B-3: Standard Specification for Soft or Annealed Copper Wire
- ASTM B-33: Standard Specification for Tinned Soft or Annealed Copper Wire for Electrical Purposes
- 90°C Temperature Rating; Temperature index in excess of 120°C
