Edbro - High Voltage Alert Safety Equipment

• Clear warning to operator of potential danger in tipping
• Reduces the risk of power line contact, improving the safety of tipping

• Compact detection antenna mounted within chassis cab
• In-cab warning unit with clear audio and visual warnings
• 12-24 volt unit easily fitted to a range of vehicles including tippers and cranes

General

• Operating voltage: 12 - 24 vDC
• Nominal operating current: < 150 mA
• Size: 130 mm (W) x 35 mm (H) x 25 mm (D)
• Weight: 155 g
• Nominal operating temperature: -5 to +55 °C
• HV detection range: Up to 100 metres (7 meters min, adjustable)
• Warning tone: Approx 85 db (high pitched pulsed buzzer)
• Visual warning: High intensity red flashing LED
• Power indicator: High intensity green LED
• Mute facility: 30 seconds *
• Mute can be activated for 30 seconds then alarm sounds until muted again

Detection Antenna

• Length: 235 mm
• Weight: 60 g
