ETA - Model X Series - Electronic Lamp Controls (ELC) System
The result of intensive research, development and many years of market experience. Developed for minimum space requirements and demanding environments. The X series combines excellent mains compatibility with a highly innovative cooling concept for reliability and flexible installation that is independent of the control cabinet. Comprehensive diagnostic capabilities via fieldbus and the eta plus safety concept complete the product.
Most popular related searches
electronic lamp control
power factor correction pfc
power factor
air cooling system
power factor correction
LED lighting
earthing system
voltage data
- Rated output: 4 kW, 6 kW, 8 kW, 12 kW, 16 kW, 24 kW, 36 kW
- Fieldbus control
- wide input voltage range from 360 V – 528 V
- significantly reduced harmonic distortion of the mains power THDi
- Protection IP 54
- innovative air-cooling system
- operation of lamps and LED modules possible
- change from lamp to LED possible
- B version with special coating for marine application
- max. ambient temperature 55°C
- up to 96% electrical efficiency
- ELC has a power factor > 0.97. It can be operated directly from the mains without any additional compensation
- power factor correction (PFC) ensures that the harmonic content of the mains current is < 5%
- the lamp emits a flicker-free radiation and has infinitely adjustable dimming over approx. 20-100% of the nominal electrical output.
- configuration, control and monitoring are achieved by means of a Profibus or Modbus controller, and the ELC X series can be easily integrated in the system control
- piling concept up to 12 modules
- the output is automatically adjusted to compensate for any variations in the mains voltage
- safe in case of short circuits or idle running
- integrated electronic lamp ignition
- integrated electronic control and monitoring systems
- integrated earth leakage detection
- fully insulated lamp output
- air cooled
- Supply voltage: 2 x 400 V ±10% or 2 x 480 V ±10%
- lamp output: 4 to 36 kW depending on unit type
- dimming range: around (approx.) 20–100%
- power factor: approx.0.97
- Protection class: IP 54
- Dimensions:
- X4: 125 x 470 x 260 mm (H x W x D)
- X6: 125 x 470 x 320 mm (H x W x D)
- X8: 125 x 470 x 420 mm (H x W x D)
- X12: 125 x 470 x 420 mm (H x W x D)
- X24: 250 x 470 x 420 mm (H x W x D)
- Weight: 11 to 42.2 kg depending on unit type
