Yatong - Enhanced Communication Twisted Pair Cables

Structure description:

• Specification of single soft copper conductor mm (04.0.5.0.6.0.7.0.8)
• White solid polyolefin insulation (high density, foamed polyethylene)
• Food polyethylene sheath, PVC sheath, low-smoke halogen-free sheath
• Tinned steel wire reinforcement
• Selectable number of pairs

• DC resistance imbalance≤1.5%
• Insulation resistance ≥10000MΩ·km
• Working capacitance ≤52 soil 2nF / km
• Unbalanced line-to-ground capacitance
• Cable installation temperature: 0 ~ 50 ° C

The main purpose
Mainly used to transmit audio, analog signals below 150kHz and digital signals below 2048kbit / s,Under certain conditions, it can also transmit digital signals below 2048kbit / s
