Ifluidtec - Ethanol Extraction Machine for Lab Research and Medium Scale Production
The Ethanol Extraction Machine by Ifluidtec is engineered for ambient pressure extraction processes across various industries, including pharmaceuticals, cosmetics, and food processing. Designed to support ultrasonic extraction and purification processes, this equipment caters to small-scale production needs, making it ideal for research institutions, universities, and laboratories. Key components include an extraction tank, tube heater, evaporator, condenser, and vacuum pump, all mounted on a robust stainless steel frame. It offers flexible extraction operations such as hot reflux circulation, conventional extraction using water or alcohol, and it meets GMP standards. The machine adapts to diverse solvent extractions and allows for multi-functional, efficient, and energy-saving applications. Optional features include alternative heating methods and an ultrasonic system for improved efficacy. With configurable parameters, such as pre-cool tanks and evaporator capacities, this equipment is optimized for high-efficiency extraction while minimizing the loss of heat-sensitive components.
Ethanol Extraction Machine Description
Small Ethanol Extraction Machine is suitable for medicine, health care products, bio-pharmaceuticals, cosmetics, food and other industries of ambient pressure extraction, ultrasonic extraction, essential oils, aromatic oils extraction, purification, and other processes. The herb extraction equipment is very suitable for universities, research institutes, laboratories, and pharmaceutical research and development departments of many varieties, small batch production use.
Lab Alcohol Extraction Machine Components and Characteristics
- The plant oil extraction machine consists of an extraction tank, tube heater, evaporator, condenser, oil separator, oil receiver, liquid medicine pump, metering tank, liquid storage tank, filter, vacuum pump, power and control cabinet, etc. The extraction tank and the steam outlet of the evaporator are equipped with a de-bubble/de-foam device. Different processes and steps are combined into one complete system.
- It can perform hot reflux circulation extraction and concentration; conventional extraction and concentration; water or alcohol as extracting solvent, percolation and other operations.
- This herb extraction system can work under negative pressure, normal pressure and positive pressure. It can adapt to water extraction, alcohol extraction or other kinds of solvents extraction, and meets GMP requirements.
- The unit has great advantages in terms of multi-function, high efficiency, energy-saving, and wide application range. In terms of comprehensive performance, it is domestically leading. It is pilot-scale extraction equipment for natural plants.
- The overall manufacturing material is 304 stainless steel; the material contact part can be 304 or 316L optional.
- All necessary parts of this extractor and evaporator are installed on a strong SUS frame, be fully inspected and tested before shipment; Very easy to install and ready to use when clients receive this set.
- Since all components are compacted designed and placed on the frame, the operation space for this extraction machine is relatively small, water source, heating source, and air source connect to extraction and concentration unit is quite easy.
- The extractant from the biomass will go through the whole system as a pre-designed workflow.
- It can be used either to get wanted ingredients or evaporate out the unwanted matter; suitable for essential oil, volatile oil and aromatic oil; juice, medicine liquid, tea and etc.
- The extraction and concentration process practice several times in this system to improve the efficiency of raw material biomass; solvents can be recycled to reduce production cost.
Extraction Machine Options for Multiple Functions
To increase the proficiency and efficiency of this extraction and concentration machine, there are several options the user can choose to add to the system.
Heating Source
Heating source is electric heating, steam heating, jacket oil heating, and jacket water heating; for plant or herbs that requires no high temperature, we can use hot water jacketed circulating heating where the extraction temperature can reach 90-95℃; Jacket oil heating is faster than water considering the thermal conductivity of oil. Factories have steam source can also apply steam heating to the extracting system. This is the fastest way to heat up. But is not suggested for heat-sensitive raw material extraction.
Stirring and Ultrasonic System
To install a set of stirrer into the extraction tank can speed up the process of biomass soaking. Or we can use ultrasonic extraction. Use a concentrating ultrasonic generator, due to the unique physical and cavitation effects of ultrasonic waves, it can promote the breakage or deformation of plant cell tissues, vibrations, acceleration shocks, and sound pressure between solute particles allowing the large volume of herbal medicinal materials to fully contact the ultrasonic probe, which accelerates the uniform precipitation of active ingredients in the substance. Thus the extraction rate is significantly improved than that of traditional processes. Ultrasonic extraction is normal temperature extraction, which effectively reduces the loss of heat-sensitive components. There is a selectable frequency range: 15KHz、20KHz、28 KHz、30 KHz、35 KHz、40 KHz、50 KHz、60KHZ
