Norcar - Model a6020 - Fastest, Strongest and Lightest Compact Loader
FromNorcar Ab
The market’s fastest, strongest and lightest compact loader in its class. With extension boom as standard, it can reach great heights and has high lifting power while maintaining agility. The driver`s seat is very comfortable with suspension seat, adjustable steering wheel and powered hydraulic functions controlled directly from the ergonomic joystick. The loader’s safety system activates the brakes automatically when the driver leaves the driver’s seat, which ensures safe and convenient operation.
Most popular related searches
- Engine
- Make : Kubota
- Model : 722
- Cylinders : 3
- Fuel type : Diesel
- Cylinder volyme cm3 : 719
- Cooling system : Fluid
- Power :
- SAE, gross power kW/hp : 15/20
- Max gross torque Nm : 46
- At engine speed r/min : 2600
- Max engine speed without load r/min : 3600
- Electrical system :
- Battery V-Ah : 12-53
- Generator A : 40
- Service volumes :
- Cooling system l : 6
- Engine oil l : 3,8
- Fuel tank l : 20
- Hydraulic tank l : 50
- Hydraulic system total volume l : 55
- Performance :
- Lifting power hydraulic kg : 1150
- Breakout force 50 cm kg : 960
- Tipping load, straight kg : 960
- Tipping load, articulated kg : 770
- Operating weight kg : 1320
- Drive speed km/h : 0-12,5
- Pulling force kg : 950
- Hydraulic system :
- Working hydraulics l/min : 28,8
- System pressure bar : 240
- Drivetrain hydraulics l/min : 63
- Drivetrain max system pressure bar : 350
- Cycle times :
- Raising boom s : 3,2
- Lowering boom s : 2,0
- Folding in bucket s : 2,2
- Tipping bucket s : 1,5
- Steering wheel rotations L/R rev : 3/4
- Tires :
- Dimension : 23 x 8,5-12 GR
