FITZER - Model WHRU -Waste Heat Recovery System

We are Leading Manufacturer & Exporter of INDUSTRIAL THERMAL PROCESS EQUIPMENT, PLANTS & MACHINERIES such as Recuperator, Regenerator, Rotary Regenerator / Heat Wheel, Passive Air Preheaters, Regenerative / Recuperative Burners, Finned Tube Heat Exchangers / Economizers, Waste Heat Boilers & Etc.

Being a Leading Solution provider of WASTE HEAT RECOVERY SYSTEM, We provide solutions to complex waste heat recovery applications for industrial users wishing to reduce operating costs and carbon emissions.

WASTE HEAT RECOVERY is a process of recovering ENERGY from waste process outputs. These are custom built equipment or systems designed as per the waste heat available and the process heat load.

• These are custom built equipment as per the type waste heat available and the process heat requirements. A detailed study of the client's system is required.

• These systems can be designed to recover waste heat from high temperature flue gases of furnaces , DG sets, boilers or any other heat source.

• The waste heat recovery can be designed in shell and tube type or water tube type design based on the operating pressure of the system.

SMOKE TUBE TYPE WASTE HEAT RECOVERY SYSTEMS :

• Package type boilers is an internal furnace Boiler with a three pass, fully wet back & smoke tube type design. The fuel is charged through a charging door to keep the fire going. Package type is designed to provide low cost heating with minimum operational complexity.

• Due to proper shell or steam drum diameters, steam volume is more & hence better steam quality.

• Steam Quality is better as Properly Designed Drum Internals are Provided.

• Provided with accessories like Economiser, Deaerator Tank etc. as per requirement for better performance of the Waste Heat Boiler.

• Capacity and Working Pressure of the Waste Heat Recovery is considered as per Customers requirement.

• Heat Exchangers and Waste Heat Recovery Boilers are especially made as per codes like IBR 1950 with its Latest Amendments/TEMA etc.

WATER TUBE TYPE WASTE HEAT RECOVERY SYSTEMS :

• Natural or Forced Circulation Type Configuration is possible.

• WHRU system is designed based on the Waste Gases Type and other Basic Design Parameters, Hence Reliable Operation.

• Smoke chambers are lined with castable refractory material to protect the inside surfaces. • Simple arrangement of smoke chamber door fixing, facilitates easy periodical tube cleaning.

• Finned Tube Construction is available which makes the WHRU compact.

• Steam Heat Recovery Boilers are available in both Bi-Drum and Single Drum type arrangements.

• Due to proper shell or steam drum diameters, steam volume is more & hence better steam quality.

• Steam Quality is better as Properly Designed Drum Internals are Provided.

• Provided with accessories like Super Heater, Economiser, Deaerator Tank etc. as per requirement for better performance of the Waste Heat Boiler.

• Capacity and Working Pressure of the Waste Heat Recovery is considered as per Customers requirement.

• Heat Exchangers and Waste Heat Recovery Boilers are especially made as per codes like IBR 1950 with its Latest Amendments/TEMA etc.

WASTE HEAT RECOVERY SYSTEM ranges from single unit to entire system which includes CO-GENERATION SYSTEMS which can generate ELECTRICITY by producing steam from running boilers operating on process outputs.

We design WASTE HEAT RECOVERY HEAT EXCHANGERS to TURNKEY CO GENERATION PROJECTS with a high degree of AUTOMATION. A detailed study of the client's system is required. Then total waste heat load is determined.

Depending on this quantity, Energy generation is calculated. Finally the system is designed for the client according to his requirements. We design and manufacture complete custom built waste heat recovery equipment by adopting best designing methods and standards along with best quality raw materials and manufacturing methods at best possible price and least possible time.

WASTE HEAT RECOVERY APPLICATION SECTORS:

1. AUTOMOTIVE INDUSTRY

2. METAL INDUSTRY

3. CONSTRUCTION INDUSTRY

4. FOOD INDUSTRY

5. MINING INDUSTRY

6. OIL & GAS INDUSTRY

7. PHARMACEUTICAL INDUSTRY

8. PRINTING PAPER INDUSTRY

9. WASTE TO ENERGY

We appreciate your interest in waste heat recovery systems and request the enquiry for future transactions.
