Model Sol 8x16 - Flashlight Solar Simulator Table System

Measures IV characteristics of PV modules—maximum power, open circuit voltage, short circuit current—at standard test conditions (STC, IEC standard 60904-1). Flash Plateau typically 10 ms. Extended version for organic cells and newer devices with flash plateau up to 80 ms. Simulated sunlight spectrally filtered to AM 1,5 global or AM 0, using Xenon flashlamps, intensity adjustable. Suited for laboratory measurements . Inverted setup (illumination from below) allows easy integration into production lines. Height only 1 m. Temporal stability, light uniformity and spectrum at STC class A.
