Inciner8 - Model I8-20S -General Incinerator
I8-20S incinerator is one of the smallest and easily maintained general incinerators we make. The i8-20S General Incinerator is a simple and effective small incinerator with suitability for various non-hazardous waste types such as wood, paper, cardboard and other uncontaminated materials. The addition of a secondary chamber allows this model to operate without smoke, odours or harmful emissions.
- Enhanced Coretex insulation
- Multi-zone temperature control
- Mobile options available
- CE2 Advanced control panel
- Modular refractory lining
- Enhanced Coretex insulation
- Multi-zone temperature control
- Mobile options available
- CE2 Advanced control panel
- Modular refractory lining
All our incinerators are hand-built in the UK by time-served welders and fabricators. Our award-winning design team are always on hand to offer their advice and technical know-how to ensure we get your project off the ground without delay.
We can also assist you in the preparation for your planning or permit application where required.
Operational Specifications
- Combustion Chamber Volume (m3): 0.18m3
- Burn Rate*: up to 20kg per hour
- Average Fuel Consumption: 4 - 6 ltrs p/h
- Operational Temperature: > 850°C
- Gas Retention in Secondary Chamber: 0.5 secs
- Temperature Monitoring: Yes
- Average ash residue (%): 3%
- Thermostatic Device: Yes
Physical specifications
- External Length (mm): 1070mm
- External Width (mm): 670mm
- External Height (mm): 3670mm
- Door Size (mm): 490 x 490
- Shipping Weigh: 800kg
For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additonal accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
