Inciner8 - Model I8-55S -General Incinerator
The i8-55s is one of our larger `S` model, It is designed to deliver performance on a budget and be a simple and effective incinerator from our medium range with suitability for various non-hazardous waste types such as wood, paper, cardboard and other uncontaminated materials. Our versatile range of ‘S’ model incinerators are designed to be multi-purpose. This particular model benefits from a top loading design and very simple operation process. Ideal as a stand-alone machine. The addition of a secondary chamber allows this model to operate without smoke, odours or harmful emissions. Fitted with a secondary chamber with afterburner functionality for the re-burn of harmful emissions through a 0.5 second retention time.
- Enhanced Coretex insulation
- Multi-zone temperature control
- Mobile options available
- CE2 Advanced control panel
- Modular refractory lining
- Enhanced Coretex insulation
- Multi-zone temperature control
- Mobile options available
- CE2 Advanced control panel
- Modular refractory lining
All our incinerators are hand-built in the UK by time-served welders and fabricators. Our award-winning design team are always on hand to offer their advice and technical know-how to ensure we get your project off the ground without delay.
We can also assist you in the preparation for your planning or permit application where required.
Operational Specifications
- Combustion Chamber Volume (m3): 0.36m3
- Burn Rate*: up to 40kg per hour
- Average Fuel Consumption: 10 - 12 ltrs p/h
- Operational Temperature: > 850°C
- Gas Retention in Secondary Chamber: 0.5 secs
- Temperature Monitoring: Yes
- Average ash residue (%): 3%
- Thermostatic Device: Yes
Physical specifications
- External Length (mm): 1520mm
- External Width (mm): 920mm
- External Height (mm): 4020mm
- Door Size (mm): 720 x 830
- Shipping Weight: 1670kg
For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additonal accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
