Inciner8 - Model I8-1000G -General Incinerator
The i8-1000G has the highest capacity of our range of general waste incinerators with suitability for various waste streams such as solid waste, MSW, RDF, wood, paper, cardboard and plastics. The flagship model within our general lineup is the i8-1000G. It took over three years to develop and is are the forefront of combustion technology, offering impressive burn rates and large batch sizes while still achieving some of the lowest emissions in its class. The i8-1000G can be customised with viewing windows, external cladding and automatic loading. It also has the benefit of being fitted with our smartpanel technology allowing operators to remotely monitor performance and see reports from anywhere in the world.
- Enhanced Coretex insulation
- Multi-zone temperature control
- Additional safety features
- CE2 Advanced control panel
- Hydraulic doors
- Landfill Alternative
- Recycling Centres
- Bigger Camps
- < 5000 People Comunities
- Industrial Waste < 8000kg day
All our incinerators are hand-built in the UK by time-served welders and fabricators. Our award-winning design team are always on hand to offer their advice and technical know-how to ensure we get your project off the ground without delay.
We can also assist you in the preparation for your planning or permit application where required.
Operational Specifications
- Combustion Chamber Volume (m3): 8.7m3
- Burn Rate*: up to 600kg per hour
- Average Fuel Consumption: 40 - 50 ltrs p/h
- Operational Temperature: > 850°C
- Gas Retention in Secondary Chamber: 2 secs
- Temperature Monitoring: Yes
- Average ash residue (%): 3%
- Thermostatic Device: Yes
Physical specifications
- External Length (mm): 6540mm
- External Width (mm): 1840mm
- External Height (mm): 6260mm
- Door Size (mm): 4000 x 1500
- Shipping Weight: 21500kg
For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additonal accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
