Ampner - Model HVPS1250C -High Voltage DC Portable Power Supply Unit for Service and Commissioning
HVPS1250C, a portable DC power supply is targeted for servicing and commissioning. It creates a galvanic isolated and stabilized output voltage up to 1250 VDC and output current up to 1 A. It is mounted in a robust case, which is easy to handle and carry on site. The weight of the unit is only 11 kg.
The power supply unit can be used e.g. for powering up frequency converters during service and commissioning or powering up the DC-link. It can also be used for capacitor recharging. In addition, thanks to the high output voltage, the DC Power supply unit enables simulating PV modules. The output voltage and current can be adjusted up to 1250 V DC and up to 1 A locally by potentiometers on the front cover.
HVPS1250C is a portable power supply unit, which creates a galvanic isolated and stabilized output voltage up to 1250 VDC and output current up to 1 A. Output voltage and current can be adjusted linearly by potentiometer. The power supply unit is also available as a fixed installed rack-model. The cable set with crocodile clips is included. Cable length 1,5 m.
- Marine
- Wind
- Solar
- Industrial
- Input voltage: 230 VAC ±15%
- Output voltage: Adjustable 0 – 1250 VDC
- Output current: Adjustable 0 – 1 A
- Voltage adjustment: Locally by potentiometer
- Current adjustment: Locally by potentiometer
- Temperature ranges
- Operation: 0 … +55 ºC
- Storage:-40 … +70 ºc
- Size (W x H x D): 410 x 170 x 320 mm
The delivery includes a cable set with crocodile clips. Cable length 1,5 m.
