J Solar - Horizontal Single Axis Tracking System
FromJSolar
Smartracker+ JTS400H-1 Horizontal Single Axis Tracking. Application Locations Mid-high latitude flat ground,mountainous terrain.
Most popular related searches
- System Type Horizontal Single Axis Tracking
- Max Capacity 409.6kwp/1280modules
- (kWp/Module) 320W
- Max.No.of Link 32Groups (1group=40 modules)
- Control Type Real-time tracking system
- Sensor Type Inclinometer sensor
- Rotating Angle +45°～45°
- Structure Materials Hot Dip Galvanized steel
- Structure Rotating System POM Bearing
- System Driving system Linear Actuator
- Input Voltage 380/460VAC/50～60hz
- Ground Coverage Ratio 1MW:14400M2 =.36
- Max.Wind Load 58m/s (130mph)
- Codes & Standards ASCE 07-10
