HSI - Model 45 -Electric Distributor

SHARE

Programmable controller allows integration with other computer controlled systems. Dial in the bin you want and start moving material.  It`s that simple with HSI`s Electronic Programmable Controller. The `in position` light illuminates when the turnspout is positioned above the desired outlet.

Most popular related searches
junction box
electrical panel

Other features include bi-directional spout rotation which significantly reduces travel time in large distributors. The DC motor is controlled by a solid state DC drive which eliminates repair and replacement of contacts and coils. Proximity switches in the distributor eliminate the problems associated with the maintenance of mechanical limit switches.

Note: The electric distributor control panel requires 110 VAC supply - no other power is required. The standard distributor is furnished with dust-tight proximity switches, junction boxes and control panel.  The TENV motor is also standard. Class II Group G Drives are available.
