Controllis - Hybrid Power Unit

Working directly with your existing site power sources the Controllis Hybrid Power Unit lets you easily add renewables, additional energy storage and remote management to your legacy power infrastructure.

The HPU allows mobiles operators to augment their existing power systems incrementally, by adding renewables, energy storage along with remote monitoring, reporting & control.

• Easily introduces solar or wind energy to reduce carbon footprint and energy costs.
• Adds a scalable Lithium-Ion battery bank for increased power autonomy.
• Controls the entire site power system remotely and reports on energy use.
• A free cooled and air-conditioned ‘drop and deploy’ cabinet with space for third party equipment. Heating options for cold climates.

The Controllis Hybrid Power Unit is a single, secure enclosure deployed next to your existing power systems, adding renewable energy sources and a scalable lithium-ion battery bank. The HPU monitors and works with and controls your existing power infrastructure to intelligently prioritise and report on the energy source used to power your site.

With the Controllis Hybrid Power Unit you can keep using your existing site power assets whilst adding renewable energy sources. You can increase your site power autonomy and add overall site power infrastructure control, analytics, and reporting.

The HPU is a scalable platform with a wide range of configuration options and includes 19’ ETSI telecom racking to accommodate and power third party equipment as needed.

Advanced hybrid controller
19’ rack-mounted controller with touch screen control
Monitors controls and reports on all site power sources
Remote connectivity to Controllis cloud management

Scalable lithium-ion battery bank
100Ah to 1500Ah high cycle life lithium-ion battery
BMS tightly integrated into Controllis cloud management

Smart programmable LVDs
250A 8 way BLVD / LLVD

Solar / wind charge controllers
Managed MPPT charge controllers, up to 20 kW capacity

DC mains rectifier
Redundant DC mains rectifier system, up to 30kW capacity

Automatic Transfer Switch
Advanced ATS deployed as needed

DC distribution and protection
Bus bars, breakers and circuit protection

Third-party equipment
Space to accommodate other telecoms equipment

The main components of the HRPS are:

• Renewable power source (usually solar).
• Power converter/chargers.
• Lithium battery storage system.
• Redundant silenced back-up generators.
• AC inverters.
• The control and monitoring system.

As with all Controllis products, HRPS is fully remotely monitored.

The connection between the HRPS and the Controllis Remote Management Server is over any IP link via cellular, fixed line or satellite.

HRPS offers a wide variety of benefits:

• Substantial reduction in carbon footprint.
• Better up-time than mains based solution.
• Reduced energy costs.
• Low maintenance costs.
• Low noise.

• 2kW to 2MW continuous average power.
• Harvesting power from renewables and storing it using batteries.
• Can harvest solar and wind.
• Full monitoring and optimisation.
• Ultra-resilient with dual or triple back-up generators.
• Generators powered by biodiesel, natural gas or biogas.
• Full carbon offsetting for generator runs.
• Turnkey systems with all components.
• Optional DC outputs.
• Modular for ease of transport and shipping.
