AW-Lake - Model HM-U - Hydraulic System Turbine Flow Meter
The HM-U Hydraulic System Turbine Flow Meter was designed specifically to measure hydraulic fluids for precise regulation and control of flow rates in hydraulic systems.
Hydraulic System Specific: Optimized for hydraulic fluids (30 cSt)
Flexible 3-in-1 Instrument : Integrated connections for optional pressure and temperature measurement
Compact, Lightweight: Machined Aluminum (DIN 3.4365) for portable applications
Bluetooth Connectivity: Easy setup using smart device for setting K-factor, alarms, totalization, and more
4 FLOW RANGES:
0.26 to 158.5 GPM (across all meter sizes)
ACCURACY:
±0.5% M.V. over full range with 30cP fluid
REPEATABILITY:
±0.5%
LINEARITY:
±2.5% of actual flow
MAX. OPERATING PRESSURE:
Working pressure up to 6,000 psi (420 bar)
FLUID TEMPERATURE RANGE:
-40°F to 248°F | 140°C to 120°C (sensor dependent)
AMBIENT TEMPERATURE RANGE:
-40°F to 185°F | 140°C to 85°C
VISCOSITY:
30cSt
END CONNECTIONS:
BSPP female
TWO ADDITIONAL PORTS:
1/4″ BSPP ports for optional temperature and pressure sensors, (customer supplied)
TURNDOWN RATIO:
up to 15:1
MATERIALS OF CONSTRUCTION:
Body: Aluminum (DIN 3.4365)
Turbine Impeller: 420RM Stainless Steel (DIN 1.4122)
Bearings: HM 007 – 011: Tungsten carbide sleeve bearing | HM 022 – 030: Stainless steel ball bearings
Internals: 303 Stainless Steel (DIN 1.4305)
EDGE SENSOR:
Output & Part Number:
Pulse Output: EDG3-1A-17S
Analog Output: EDG3-1B-17S
Modbus Output: EDG3-1C-17S
