Atawey - Model Evolutive -Hydrogen Station
Scalable stations address the heavy and light mobility markets with medium and large capacities ranging from 100 kg/d to 1.3 t/d. Their distribution capacity evolves over time according to the increase in the number of vehicles to be refueled.
Adaptable
Start a hydrogen system rapidly with a few vehicles and then expand the station according to your needs
Reduced footprint
Only one 20-foot container for utilities and compression, facilitating the installation and construction work.
Availability, reliability and efficiency
Fast, cooled refueling, optimized energy consumption, redundancy of key elements
Sustainability
zero emissions for trucks and light vehicles
Multi-terminal
For simultaneous charging of several vehicles
Hiflow
to refuel HGVs in less than 15 minutes
Export & import posts
To facilitate hydrogen logistics by tube trailers
Legal metrology
To charge for retail hydrogen fill-ups
Controlled operating costs
Energy efficient design using cascading stock valorization
Our stations meet European standards
Maximum level of safety
We perform Hazop, Atex and Lopa safety studies and ensure the station’s safety in the event of a hydrogen leak (ICPE 1416 standard)
A rapid filling system
Complies with the standards in force: SAEJ 2601 for light vehicles and CEP for heavy vehicles
Connected Station
Intelligent automated safety and monitoring system
100-300kg
350 and 700 bar T40 cooled
Footprint: Two 20ft containers for compression and utilities, external hydrogen storage and cooling unit, external distribution terminal
Source electrolyzer or tube trailers
Upgrade capacity from 100 to 300kg
400-800kg
350 and 700 bar T40 cooled, Hiflow optional
Footprint: One 20ft containers for compression and utilities, external hydrogen storage and cooling unit, external distribution terminal
Electrolyzer source
Upgrade capacity from 400 to 800kg
800kg / 1,3T
350 and 700 bar T40 cooled, Hiflow optional
Footprint: One 20ft containers for compression and utilities, external hydrogen storage and cooling unit, external distribution terminal
Source tube trailer 200 to 500 bar
2 versions: 800kg or 1.3T distributed per day
