Olymp PelletStar - Lambda Condens
Pellets are standardized, cylindrical rolls made from natural wood residues. The production takes place without binders and additives and only requires 1% of the amount of energy contained in the fuel. As with wood, combustion is CO2-neutral and therefore also makes an important contribution to climate protection. The new PelletStar Lambda from Olymp is characterized by an exceptionally high degree of efficiency with extremely low emissions. At the same time, it offers the greatest possible operational safety and ease of use.
- Nominal heat output: 3.4 to 60kW
- Highest efficiency through lambda probe
- Automatic heating mode
- Stepless control of the heat output
- Fully automatic cleaning of the heat exchanger surfaces
- Ash container easily accessible from the front
- Optimal operational safety through grate cleaning
- Particularly low space requirement due to compact dimensions
- Various fully automatic discharge systems with flexible screw, suction conveyor or mole systems or with 4-point suction from a storage room or bag silo.
- Alternatively, there is also cost-effective manual filling (without storage room or bag silo)
The PelletStar Lambda Condens – the first pellet boiler with condensing technology.
The combustion technology at the highest level and the high-quality system components result in an increase in the efficiency of the pellet systems and a reduction in dust emissions. The extremely compact condensing boiler with 8 output sizes from 3 to 60 kW is the ideal solution for both new buildings and modernization.
Maximum efficiency.
The water vapor contained in the exhaust gas is cooled down to such an extent that liquid condensate is formed. During this cooling (liquefaction), heat is released and used for heating purposes, whereby efficiencies of almost 100% can be achieved.
Ideal for radiators and underfloor heating.
The OLYMP PelletStar Condens condensing boiler is the ideal solution for both new buildings and modernizations. The heat distribution can take place via a low-temperature or a high-temperature system.
The delivery systems.
With the new PelletStar Lambda series from OLYMP, heating with wood pellets is clean and safe. This includes the correct storage of the pellets (storage room or bag silo) and the correct room discharge system.
The flexible screw discharge:
The room discharge by means of a flexible discharge screw is a simple and energy-saving system with optimal emptying of the storage room.
Figure with pellet storage room.
Discharge by means of suction:
Suction conveying is recommended for larger distances between the storage room / sack silo and the PelletStar Lambda. The suction conveyor system guarantees efficient storage space emptying and a particularly low space requirement!
Illustration with sack silo.
