JUNXY ENERGY - Model JUNXY-AC400V-100KW -JUNXY Series Resistive AC Load Bank

SHARE
JUNXY Series Pure Resistive AC Load Bank(R-AC) Purely resistive load bank is the most common type of load bank, and it proves equivalent loading of both generator and prime mover. That is, for each kilowatt of load applied to the generator by the load bank, an equal amount of electrical energy converts to heat by power resistors, in a general way, this heat must be dissipated from the load bank by air forced means or other convection. The JUNXY's resistors are made by high quality finned tubular heating elements, they are of the type where the surface area is enlarged by a strip in order to heat gases. At high power the surface temperature is small and the heating element is short. Meanwhile, Load elements are cooled usually via Fan Forced Air, blower power is typically provided by an outside source. Selected load banks are available with blower power derived from the power source under test.
Most popular related searches
load bank
resistive load bank
AC resistive load bank
tubular heating element
power resistor
circuit breaker
energy conversion
heat to power
power testing
power test

Technical Specifications




Load Voltage

(Select one)
1φ2W+G(50/60Hz): 120V, 220V, 230V, 240V
3φ4W+G, Y connection(50/60Hz): 190/110V, 200/115V, 208/120V, 220/128V, 230/132V, 240/139V, 380/220V, 400/230V, 415/240V, 440/254V, 460/265V, 480/277V
3φ3W+G, Delta connection(50/60Hz): 220V, 230V, 240V, 380V, 400V, 415V, 440V
Or other load voltage as per required
Load Power
100KW
200KW
300KW
500KW
800KW
1000KW
PF
PF=1
Load Step
Minimum 100W
Minimum 1KW
Digital Meter
U, I, P, F, PF.
Protections
Standard & Optional protections as above listed
Control Modes
Manual: circuit breakers or push buttons or toggle switches. Auto: PC software remote control
Cooling
Vertical or horizontal force-air cooling
Dimension(cm)
60*85*130
70*137*135
120*137*161
130*147*180
150*180*180
180*200*180
