Leon Solar - Adjustable Tilt Mounting System
The adjustable tilt mounting system will easily fit different flat roofs or open terrain applications, due to its variable tilt angle and footing options for both roof clamp and roof penetration. It can be used as fixed or adjustable tilt, allows for project-specific adjustments and optimize solar output.
Most popular related searches
The innovative design and high pre-assembly eliminate the need for on-site cutting, welding and enable quick and easy field operation.
Optional:
- 10-15 degree
- 15-30 degree
- 30-60 degree
- Max wind capacity:42m/s
- Max snow capacity:1KN/m2
- Span range:0.6-2.5m
- Installation angle deviation:±2°
- Adjustable angle:10-15,15-30,30-60
- Design standard:AS/NZS1170, ASCE 7-05, DIN1044
- Technical Paramameter
- Installation site: Metal roof
- Main material:AL6005-T5
- Fastener material:SUS304
- Applicable modules:framed
- Component arrangement: vertical
- Warranty period:10years
