HyperStrong - Model HyperBlock III - Liquid-Cooling Energy Storage System
The HyperBlock III is a high-efficiency battery energy storage system designed for utility-scale applications, incorporating an advanced liquid-cooling mechanism. With a substantial battery capacity of up to 5MWh, HyperBlock III offers a 34.5% boost in energy density, making it a prime choice for extensive energy storage needs. The system integrates essential components like the battery pack, PDU, and string power conditioning system, significantly reducing commissioning time by over four hours. The intelligent design features smart liquid cooling to maintain optimal cell performance and prolong battery life while adapting to various thermal conditions to improve energy efficiency and cut operating costs. The system's robust safety features include digital modeling technologies for AI-based early warnings and a multi-dimensional sensing system for continuous safety monitoring. It supports improved power scheduling with precise battery state algorithms and enhances the overall discharge capabilities, thanks to intelligent regulation of battery racks.
HyperBlock III, a battery energy storage system integrated with a liquid-cooling system, provides high efficiency and flexibility for the utility-scale. With up to 5MWh battery capacity, HyperBlock III can offer a 34.5% increase in energy density, serving as an ideal choice for utility-scale battery storage.
Low LCOS
Save footprint and on-site workload
Maximize Battery Longevity: smart liquid cooling system maintains the optimal performance of cells and PCS throughout their lifecycle
Reduce Auxiliary Power Consumption: thermal control strategies adapt to various conditions, enhancing energy efficiency and cutting costs
Safe and Reliable
Early Safety Alerts: Digital modelling technologies enable AI analysis throughout the cell`s lifecycle, providing early warnings for cell safety
Intelligent Safety Monitoring: A multi-dimensional sensing system tracks cell, electrical, and structural safety, ensuring active safety management
Comprehensive Protection: Multi-level electrical protection and fire suppression design enhance overall safety
Highly Integrated
Up to 5MWh Capacity: 34.5% increase in energy density
Efficient Design: Integrated battery pack, PDU, and string PCS reducing the commissioning time by over 4h
Flexible Installation: Single-side opening design optimizes space and saves O&M workload
Efficient and Flexible
Improved RTE: Precise battery state algorithm optimized battery rack operation for power scheduling, increasing the power station`s round-trip efficiency (RTE) by 2%
Enhanced Discharge Capacity: Intelligent regulation of each battery rack`s charge and discharge boosts the system`s ov
- Product : Liquid-cooling ESS
- Model : HSL3C721-05015
- Battery Cell : LFP-314Ah
- Configuration : 12P416S
- Rated Energy (kWh) : 5015.96
- Rated Voltage (V d.c.) : 1331.2
- Rated Power (kW) : 2500 @25?
- Rated AC Power (kVA) : 2500 @25?
- Rated Frequency : 50Hz/60Hz
- Dimensions (W*D*H) : 6058*2438*2896mm
- Operating Temperature : -30~55°C (> 45? derating)
- Cooling Method : Smart Liquid Cooling
- Certifications : UN38.3, IEC61000, IEC62933-5-2, IEC62619, IEC60730, IEC63056, IEC62477, UL9540A, UL9540, UL1973, NFPA855
