Model LPC8N04 - Low-Cost Microcontrollers (MCUs) based on Arm® Cortex®-M0+ Core

FromNXP

SHARE

LPC8N04 is a cost-effective MCU which serves as an entry-level connectivity solution for embedded applications with integrated NFC connectivity. The LPC8N04 MCU contains multiple features, including several power-down modes and a selectable CPU frequency of up to 8 MHz for ultra-low power consumption. The peripheral complement of the LPC8N04 MCU includes 32 kB of flash memory, 8 kB of SRAM, 4 kB of EEPROM, one I2C, one SPI/SSP, and up to 12 general purposes I/O pins.

Most popular related searches

brushless DC motor

brushless DC motor control

induction motor

electricity grid

domestic energy

permanent magnet motor

smart lighting system

electrical heating

System

Arm® Cortex®-M0+ core running at frequencies of up to 8 MHz
Nested Vectored Interrupt Controller (NVIC)
Arm Serial Wire Debug (SWD)
System tick timer
IC reset input

Memory

32 kB on-chip flash programming memory
8 kB SRAM
4 kB on-chip EEPROM

Digital peripherals

Up to 12 General-Purpose I/O (GPIO) pins with configurable pull-up/pull-down resistors and repeater mode
GPIO pins which can be used as edge and level sensitive interrupt sources
High-current drivers/sinks (20 mA) on four GPIO pins
High-current drivers/sinks (20 mA) on two I2C-bus pins
Programmable Watchdog Timer (WDT)
Real-Time Clock (RTC) Timer

Communication interfaces

NFC/RFID ISO 14443 type A interface
Serial I2C-bus supporting full I2C-bus specification and Fast-mode with a data rate of 400 kbit/s, with multiple address recognition and monitor mode
SPI/SSP interface

Clock generation

8 MHz internal RC oscillator, trimmed to 2% accuracy, which is used for the system clock
Timer oscillator operating at 32 kHz linked to the RTC timer unit

Power control

Support for 1.72 V to 3.6 V external voltages
The LPC8N04 can also be powered from the NFC field
Activation via NFC
Integrated Power Management Unit (PMU) for versatile control of power consumption
Four reduced power modes for Arm Cortex-M0+: sleep, deep-sleep, deep power-down and battery-off
Power gating for each analog peripheral for ultra-low power operation
< 50 nA IC current consumption in Battery-off mode at 3.0 V
Power-On Reset (POR)

Additional features

Temperature sensor with +/- 1.5°C accuracy from
- 40°C to 85°C
Unique device serial number for identification
