Model GB-Sol 220W –225W -PV Module
FromGB-Sol Ltd.
A custom, high quality crystalline silicon cell module, produced at our Pontypridd production facility near Cardiff. These products can be provided as a conventional framed panel or as a laminate for BIPV use, typically in conjunction with our RIS in-roof system. Supplied in either silver framed white background or the popular black framed black panel versions. We operate a Low Carbon Supply Chain utilising local suppliers wherever possible and have been manufacturing quality British panels in the South Wales area since 1994.
Most popular related searches
crystalline silicon
junction box
solar panel
photovoltaic module
carbonization
BIPV
crystalline solar cell
solar panel module
solar module production
solar panel production
- 54 connected 156 mm x 156 mm high efficiency crystalline silicon cells.
- 4mm low iron toughened glass maximising panel efficiency and strength.
- (Many competitors only use 3.2mm thick glass)
- Fitted with an anodised aluminium frame or EPDM edge gasket if supplied as a laminate
- frameless version for our RIS system .
- IP65 Junction Box including bypass diodes
- 1.5m cable terminated to MC4 connectors
- High strength design with maximum surface loading, tested up to 5400 Pa.
