Model IB980 -Inverted Bucket Steam Trap
The IB980 Series Inverted Bucket Steam Trap is a robust and efficient solution for steam management in industrial applications. Crafted from high-quality cast iron, this steam trap is designed for durability and reliability. Available in sizes ranging from 1/2 inch to 3 inches, it supports both NPT and BSPT screwed ends, as well as PN, JIS, and ANSI flanged ends, making it versatile for various piping configurations. With a maximum operating pressure of 17 KGS and a working temperature capacity of 230°C, it can handle demanding conditions. The IB980 Series meets ISO 9001:2008 standards, holds a Manufacture License of Special Equipment for PN4.0 Mpa, and is patented under ZL 2009 2 0003337.2, ensuring compliance and innovation. This series is ideal for ensuring efficient condensate removal and preventing steam loss, making it a critical component in maintaining system efficiency and safety.Most popular related searches
Specification
Size (Screwed End): 1/2" - 2" (DN15 - DN50)
Size (Flanged End): 1/2" - 3" (DN15 - DN80)
Connection End
NPT and BSPT Screwed End
PN/JIS/ANSI Flanged End
Maximum Operating Pressure: 17 KGS
Working Temperature: 230°C
NO.IB980 Series DIMENSIONS (MM). MOP(KG/CM^). WT(KG)
