Model PW3335 -Power Meter

SHARE

Measure AC/DC Standby Power Up to Large Power Loads.

Most popular related searches
standby power
power meter
power analyzer
power factor
power monitoring
transformer testing
  • Compatible with the SPECpower® benchmark for server power consumption SPECpower® is a registered trademark of Standard Performance Evaluation Corporation
  • High-precision ±0.1% basic accuracy (For complete details, please refer to the specifications) • Wide 1mA to 20A measurement range, max. continuous input of 30 A.
  • Wide frequency bandwidth of 0.1 Hz to 100 kHz or DC
  • Measure harmonic and standby power consumption according to IEC62301
  • Achieve superior accuracy even with a low power factor for no-load testing of transformers and motors
  • Synchronized control using up to 8 instruments
  • Built-in external sensor input terminals to measure up to 5000 A AC (PW3335-03, PW3335-04 only)
  • Send measured values to HIOKI data loggers using a Bluetooth® wireless technology compatible adapter (LR8410 Link-compatible products, Ver. 1.1 and later, the PW3335-01 is not supported)
