Model SP Lite2 - Silicon Pyranometer for Radiation Measurements
Cost-effective solar sensor to measure global radiation, for use in all weather conditions. A silicon photocell transforms the incoming radiation into an analogue mV signal. Affordable pyranometer for routine measurements, Compact and light, Easy to use, low maintenance required, Can combine 2 sensors to function as an albedometer
Most popular related searches
Measuring range: | 0 to 2,000 W/m² |
Sensitivity: | 60 to 100 μV/W/m² |
Spectral range: | 400 to 1,100 nm |
Output signal: | Analogue 0 - 20 mV; 4 - 20 mA (with extra module) |
Operating temperature: | -30 to +70°C |
Dimensions: | 84 x 110 mm (height x diameter) |
