Neocab - SolarCable
NEOCAB®one of the most trusted brands in cables & conductors, was created with aim to cater high-quality premium cable products to the market. Though times we catered products that required high-end INNOVATION and RESEARCH. NEOCAB®-PV`s SOLAR Cables are a step towards creation of enviornment friendly cables for development of ELECTRICITY through SOLAR-power.NEOCAB®-PV is our efforts to take part in ENERGY CONSERVATION. Our range of PV-CABLES(also known as SOLAR CABLES) are more ADAPTIVE, more ROBUST, RUGGED and more VERSATILE than ever before. These cables are made in compliance with international standards such as RoHS and CE Certified.
NEOCAB®-PV solar cables are exclusively made for applications in photovoltic power systems. A solar cable interconnects solar panels and other electrical components of photovoltic system. These solar cables are designed to be UV & Ozone resistant, Chemical and Oil resistant, with excellent FR properties, propagates smoke with low opacity when forced burned with external source and contains absoluetly ZERO or Low halogen. This cable can survive extreme weather conditions. It can be used whithin a large temprature range and generally laid outside. These cables can be installed at indoor, outdoor, in hazard areas, in explosion areas, in industry and in agriculture.
Solar cable generally not installed in places where its directly exposed to sunlight however throughout the day time they are continuously exposed to diffused to indirect sunlight. Moreover they may need to face extreme weather conditions and harsh hand Considering these conditions we have developed certain range of Solar Cables which can be used according to prevalent condition of installation site. We also develop tailor made solar cables as per customer`s requirements.
- Annealed Bunched Flexible Copper Conductor with ETP Copper with 99.97% purity and 101% conductivity.
- Tinned copper bunched flexible conductor with ETP Copper with 99.97% purity and 101% conductivity.
- Double insulated Cross-linked Fire Retardant Low smoke zero halogen with conductor temprature rating 120 °C
- Double insulated Flexible insulation with Fire Retardant Low smoke zero halogen with conductor temprature rating 105 °C
- Double Insulated:
- First Layer Cross Linkable Thermo set Polymer with Conductor Temperature Rating 90° C
- Second Layer UV Stabilized FRLS-H Sheath
- Lifetime Reliability: Lasts up to 30 years even under tough external conditions.
- Outdoor Durability: Resists extreme tempratures (-40°C to 120°C maximum at the core) and ozone resistant.
- UV resistance: Full protection against ultraviolet rays.
- Halogen-Free: Low smoke emmission & Low Toxicity / Crositivity during fire.
- Properties against Fire:Flame Retardant.
- Flexibility and Strip-Ability:For fast and easy installation.
- Fully Recyclable:In accordance with new environmental regulations.
- Easy Installation with color identification(blue,red)
- Suitable to common connector types.
- Single cable accoding to DIN VDE 0482 Part 332-1-21 DIN EN 60332-1-2
- Multiple cable according to DIN VDE 0482 Part 266-2-1 , DIN EN 50305-9
- Low Smoke emission according to DIN VDE 0482 Part 268-1 & 2
- DIN EN 61034 & DIN EN 50268-2 (light transmittance < 70% )
- Corrosively according to DIN EN 50267-2-2
- Toxicity according to DIN EN 50305
