R&X Energy - Model 15KW 300RPM 360RPM -Permanent Magnet Synchronous Generator 220V 380V 400V
Radial flux permanent magnet generators offer high efficiency, compact design, strong torque density, low maintenance, and reliable performance due to their simple structure and brushless operation.
Most popular related searches
- Rated Power(W)::15KW
- Rated Speed(RPM)::360R/M
- Frequcy:60HZ
- Rated Voltage(V)::AC220-480V
- Insulation Class::F
- Efficiency (%):93
- Generator type:3 -Phase Permanent Magnet AC Synchronous Generator
- Service Life::over 20 years
- Working Environment:-35º C-60º C
- Speed Range:0-300 rpm
- Mechanical specifications
- Mounting Means:Horizontal/ Vertical
- Approx Gross Weight(Kg):200.0
- Rated Toque(N*M):395
- Start Torque(N/M):15
- Poles:20
- Material specifications
- Shaft Material:Iron with quenching and tempering Treatment
- Bearing:HRB or as your request
- Lubrication:Lubrication Grease
- Shell Material:Carbon Steel
- Winding Temperature Class:150 Centigrade
- Permanent Magnet Material:Rare Earth NdFeB
- Permanent Magnet Material Temperature Class:150 Centigrade
- Core:High Grade Cold Rolling Silicon Sheet 50WW470
- Protection Grade:IP54
