Maike - Planar Transformer
Current transformer is an instrument that converts large current on the primary side into small current on the secondary side based on the principle of electromagnetic induction. The current transformer is composed of a closed core and windings. Its primary winding has a small number of turns and is strung in the circuit of the current that needs to be measured.
Planar transformer is a transformer with high frequency, low profile, small height and high operating frequency. Compared with conventional transformers, the size of the magnetic core of planar transformers is greatly reduced, especially the height is reduced the most. This feature is very attractive in power supply equipment where space is strictly limited, making it the preferred magnetic component in many power supply equipment. The structural advantages of planar transformers also bring many advantages to its electrical characteristics: high power density, high efficiency, low leakage inductance, good heat dissipation, and low cost.
