Plasma Arc Treatment
Eltech`s Plasma Arc treatment system is perfect solution to adhesion problems on injection, blow-molded or extruded parts of PE, PP, PET, nylon, vinyl, polystyrene, polycarbonate, PVC, fluorocarbons and all other types of thermoformed and thermoset plastics. The plastic surface treatment is achieved with Plasma Arc treatment. Plasma Arc can be used in a very flexible way since since a counter electrode is not needed. Atmospheric Plasma Treatment can be used in a very flexible way since a counter electrode is not needed. The discharge is ignited between a pair of electrodes inside the treatment tool and gets directed towards the substrate with minor laminar airflow.
| SINGLE HEAD | DUAL HEAD | |
| Model | aplasma-AC-1000 | aplasma-AC-2000 |
| Input Voltage | 230 V AC, ± 5 % ,1 Ø , 3 Wire | 230 V AC, ± 5 % ,1 Ø , 3 Wire |
| Input Frequency | 50 Hz ± 5 % | 50 Hz ± 5 % |
| Plasma Current | 3.5 Amp | 4 Amp |
| Output Voltage | 3-5 KV | 3-5 KV |
| Output frequency | 40 KHZ | 40 KHZ |
| Output power | 700 Watts | 1000 Watts |
| Max. Ambient Operating Temp. | 0 ~ 50°C | 0 ~ 50°C |
| Discharge Head | 1 | 2 |
| Compressed Air Supply | ||
| Discharge Width | 40 mm | 40 mm x 2 Head |
| Dimensions | 465mm X 310mm x 775mm | 465mm X 310mm x 775mm |
| Weight | 40 kg | 46 kg |
| Certifications | CE, RoHs, ISO | CE, RoHs, ISO |
- Applying to all kinds of materials of conductivity & non-conductivity
- Easy operation by simple button ON/OFF and Start/Stop
- Ultra high frequency using latest IGBT technology
- Long Lasting, Uniform, High surface treatment levels
- Ideal for integration with industrial automation
- Reliable industrial design
- Ideal for high speed lines
- Customized Design
- Overload Trip
- Thermal trip for heatsink
- MCB protection
- Under voltage / Over voltage
- Door open
- Audio / visual alarm
- Under current / Over current
- No Air
- Forced cool convertor for longer life
- Easy to maintain
- Easy to install
- Cost efficient treatment process
- HV transformer is able to used for long hours and continous work
- Maximum operator safety
- Soft start
- Compact simple contruction
3D Corona treatment system readily solve surface adhesion problems for a wide variety of products and applications:
- Caps and closures
- Cups and containers
- Painting and decorating
- Consumer products
- Extruded pipe, tubing, profiles
- Medical and health care products
- Electrical/electronic components
- Direct printing
- Hot stamping
- Laminating
- Pad printing
- Adhesive coating
- Wire and cable
