Plus Solar Cable
Its excellent insulation material, the cable is particularly water repellent and can be laid directly underground. UL2566 (internal examination) Long-term insulation resistance test in water bath at 90°C >3GΩ*m (internal examination).
Most popular related searches
- Because of its excellent insulation material, the cable is particularly water repellent and can be laid directly underground. UL2566 (internal examination) Long-term insulation resistance test in water bath at 90°C >3GΩ*m (internal examination)
- Nominal voltage: 1,5kV DC and 1,0 kV AC
- Maximum permitted operating voltage: 1,8kV DC (Internal examination: 2,0kV DC)
- Short-circuit-temperature: 250° C/5s
- Reinforced cable sheath: Impact-Resistance UL 854.23 and Crushing-Resistance UL 854.24 (internal examination)
- UV stability: Tensile strength and ultimate-elongation after 720 h (360 cycles) ≥ 70% of initial values; EN 50289-4-17 acc. method A; EN ISO 4892-1 (2000) and EN ISO 4892-2 (2006)
- CPR-classification of burning behavior: Eca Declaration of Performance DoP 0743
