Starworld - Model SW-300W -Polycrystalline Solar Panel

Soalr cell 156*156mm. No.of cells 72 pcs ( 6*12 ). Dimensions 1956*992*40mm. Weight 23.0kg. Front Glass 3.2mm tempered glass. Frame Anodized aluminium alloy. Junction Box IP65/IP75 rated (3 bypass diodes). Connectors MC 4 compatible. Mechanical load test 5400Pa. Operating module temperature -4℃ to + 85℃. Maximum system voltage 1500V DC (IEC)/600VDC (UL). Maximum series fuse rating 15A. Power tolerance 0/+5W.
