Hydra-Tech - Model HT35DYS - Portable Hydraulic Power Unit
FromHydra-Tech Pumps
This diesel power unit is powered by a Yanmar diesel engine and is designed to drive several of our pump models including the S4VHL and S6TC. A large, built-in fuel tank allows this unit to run up to 24 hours between refills. Other equipment that require flows to 20 GPM may also operate from this power unit.
Most popular related searches
hydropower
portable hydraulic power unit
diesel power unit
hydraulic power unit
fuel tank
diesel power
diesel engine
- H 64″ (163 cm) x W 58″ (147 cm) x L 105″ (267 cm)
- Weight: 1420 lbs. (643 kg)
- Hydraulic Oil: SAE 10W or 20W Type AW (also: Dexron ATF or Biodegradable oil)
- Engine: Yanmar 3TNV88 Liquid Cooled Diesel (Tier 4 Int.)
- Horse Power: 36.8 HP(26 KW) @ 3000 RPM
- Hydraulic Output: Variable, Max. 20 GPM (76 LPM) @ 2500 PSI
- Hose Port Size: 3/4" NPT
- Oil Filtration: 10 Micron (Standard)
- Oil Reservoir Capacity: 30 U.S. Gallons (114 Liters)
- Fuel Tank Capacity: 42 U.S. Gallons (159 Liters)
- Fuel Consumption: Approx. 2.5 Gal/Hr (9.5 Liters/Hr)
- Dimensions: H 64″ (163 cm) x W 58″ (147 cm) x L 105″ (267 cm)
