Burckhardt Compression - Model BCS -Process Gas Compressors
BCS Process Gas Compressors are available up to 200 bar/2’900 psi (lubricated) and 70 bar/1’015 psi (non-lubricated) discharge pressure. The modular compressor design enables cost-efficient engineering and manufacturing resulting in a capex-oriented compressor system, according to API 618 requirements. Services and spare parts management is available worldwide through the global Burckhardt Compression network.
- API 618 compliant Process Gas Compressors from 42 to 1’250 kN gas load (9’448 – 225’000 lbs)
- Proven technology since over 25 years
- State of the art processes and fabrication
- Bare compressor to turnkey solutions
- Capex-optimized design
- High degree of standardization
- Short lead time
- Easy maintenance
- Integrated in the Burckhardt Compression global service and spare parts network
- API 618 compliant Process Gas Compressors from 42 to 1’250 kN gas load (9’448 – 225’000 lbs)
- Proven technology since over 25 years
- State of the art processes and fabrication
- Bare compressor to turnkey solutions
- Capex-optimized design
- High degree of standardization
- Short lead time
- Easy maintenance
- Integrated in the Burckhardt Compression global service and spare parts network
Type: No. of references
P/D 3.5 (42 kN): 210 units
D/M 6.5 (65 kN): 236 units
D/M 10 (100 kN): 496 units
D/M 12 (120 kN): 261 units
D/M 16 (160 kN): 231 units
D/M 20 (200 KN): 353 units
D/M 25 (200 KN): 168 units
D/M 32 (320 kN): 385 units
D/M 45 (450 kN): 213 units
D/M 80 (800 kN): 217 units
D/M VL (1000 kN): 6 units
D/M HE (1 250 kN): 55 units
- 4 machining shops
- 1 assembly workshop
- Packaging workshop
- Own foundry
- Fast delivery: Bare shaft compressors 6 – 10 months, Packages 8 – 12 months
- New factory opening in 2020
State of the Art Quality and In-House Testing Facilities
- Mechanical and chemical testing competencies
- Destructive and non-destructive testing
- Metallographic examinations
- Various calibration possibilities
- Facilities and processes certified acc. to: ISO 9001:2015, ISO 14001:2015, OHSAS 18001:2007, API Q1
- Laboratory accreditation certificate acc. to ISO/IEC 17025:2017
Flexibility Through In-House Foundry
- ASTM materials for international markets
- Short lead times through flexible slot-planning
- Best material quality through state of the art processes
- Optimized carbon foot-print, using electric furnaces
- On-Site materials lab
Diverse Configuration Options
- Bare-shaft compressors
- Foundation mounted compressor systems
- Integrated compressor systems, fully engineered in-house
- Packaged and fabricated in-house for various markets: sea-can packages, single-lift packages, multi-lift packages
