AUTOL - Model SSVA - Progressive Block Divider
Autol specializes in advanced centralized lubrication systems designed for various heavy-duty applications. Their state-of-the-art solutions cater to industries such as construction machinery, commercial vehicles, wind power, mining, ports, food and beverage, and agricultural machinery. These systems offer essential lubrication to critical components, significantly reducing mechanical failure rates, extending equipment life, and optimizing operational efficiency. The product lineup includes progressive, dual-line, multi-line, single-line lubrication systems, and specialized devices like ALP01 single point lubrication pump and ALP812 lubrication pump. Additionally, they provide waste lubricating grease collection systems to manage lubrication by-products and improve environmental sustainability. Their technology addresses the issue of up to 60% mechanical failures caused by inadequate lubrication in machinery, thus offering a reliable solution to enhance maintenance processes and equipment performance.
- Content: Parameter
- Operating temperature: -40℃~80℃
- Outlet flow: 0.2ml/cy
- Number of outlets: 6-22
- Operating
- pressure: 35MPa
- Start-up
- pressure: ≤2MPa
- Applicable
- grease: NLGI-0#, 1# & 2#
- Inlet/outlet
- thread: M10X1
Through sequential actions of plungers, the progressive distributor progressively supplies lube points. It may be constructed with blocks or pieces. A block-type distributor is structured with one block, with outlet being connected with 6/8/10/12/14 ways, with high operating pressure, suitable for heavy-duty machinery. A piece-type distributor consists of one front piece, one rear piece and intermediate pieces. Each intermediate piece is designed with 2 outlets. Each group of intermediate piece include 3 to 8 pieces. Each delivery may be independently design, depending on plunger area and stroke
- SSVA type metering device is a compact single block progressive metering device. For direct mount of fittings with no need of any sealing inbetween.
- Available with pin indicator for visual system monitoring or with piston detector for electrical system monitoring.
- The outlets of SSVA are up to 20, max operating pressure is 35Mpa. SSVA is suitable for progressive greasing system, widely used in many fields,such as construction machinery,wind turbine.
