YTL - Model J119007 -Real-Time Tasks 220V, 50-60HZ Concentrator with Ethernet Communication
Model ES212C is a concentrator with GPRS communication which can receive the real-time tasks issued by the master station through GPRS, read the measurement data of the measuring device regularly and upload it to the master station. In addition, it can receive the data uploaded by the electricity meter actively through RS485 and upload it to the cloud.
Most popular related searches
electricity meter
power sensor
energy saving
energy smart meter
electrical power meter
smart power meter
smart electricity meter
energy meters
electric power
electrical power
- Reference voltage： 220V±20%
- Rated frequency： 50Hz-60Hz
- communication： up link：GPRS down link：RS485
- RS485 baud rate： 38400
- Ethernet： GSM850/900，DSC1800，PCS1900
- communication
- working
- blue button: Long press 5-9S, release the button after the first fast blinking of LED B, restart.
Long press 14-18S, release the button after the second fast blinking of LED B, factory reset.
Notes: Press the button to keep LED B permanently on, and release it when LED B fast blinking.
Material
- Base： PC+ABS Alloy material
- Cover： PC+ABS Alloy material
- Terminal cover： PC+ABS Alloy material
- Terminal block： PC+ABS Alloy material
- Lock： ABS
- Height 90.0mm
- Width 36.0mm
- Depth 72.0mm
