FCT Systeme GmbH
FCT - Model Type FH W -Resistance Heated High-Temperature Vacuum Sintering Furnace
FromFCT Systeme GmbH
These horizontal, resistance-heated sintering systems are used in many areas of application, as they can be operated both in a vacuum and in an inert atmosphere. The main area of application is the debinding and subsequent sintering of ceramics, composite materials or powder metallurgical components.
Most popular related searches
high-temperature sintering furnace
sintering furnace
high temperature furnace
furnace
silicon nitride
gas main
carbonization
wall heating
heating and cooling
They are used in particular for high-temperature processes such as carbonization, recrystallization, silicon infiltration, nitriding (formation of Si3N4), vacuum sintering or metallization. Optionally, these systems can be equipped with a debinding/dewaxing system as a combined process. Rapid cooling is also available to significantly reduce cooling times.
- sintering in vacuum, partial pressure, relative pressure
- Debinding and/or dewaxing as a combined process
- High flexibility in process optimization and design
- Extensive data evaluation
- Prototype production, series production
- Design: horizontal with swivel door
- Temperature measurement using pyrometer
- Working temperature up to 2200°C
- Vacuum: 5x10-² mbar(a)
- Furnace atmosphere: Ar / N2 / forming gases
- Easy accessibility
- Resistance heating
- Double-walled, water-cooled vacuum vessel
- Comprehensive, user-friendly Siemens S7 and WinCC control system
- Working temperature up to 2400°C
- Various gas mixtures can be regulated
- Debinding / dewaxing
- Rapid cooling with internal gas circulation
