Wantai -Â Model SS758 - Servo Driver
SS758 Servo Driver adopts the latest dedicated motor control DSP chip and application of vector type closed-loop control technology, thus completely overcoming the problem of open-loop stepper motor losing steps, while also significantly improving the high-speed performance of the motor, reducing the degree of heat generation and reducing the vibration of the motor , And improve the processing speed and accuracy of the machine and reduce the energy consumption of the machine. In addition, when the motor is continuously overloaded, the driver will output an alarm signal, which has the same reliability as the AC servo system. The installation size of SS758 adapted motor is fully compatible with the traditional 86 series stepper motor, and the traditional stepper drive scheme is very easy to upgrade.
- Adopt a new 32-bit motor control dedicated DSP chip;
- Adopt advanced vector-type variable current closed-loop control technology;
- Can be derived to contain the motor brake control function;
- Can be derived to contain encoder output function;
- Can drive 57 series, 60 series, 86 series hybrid servo motors;
- Signal optocoupler isolation differential input;
- Impulse response frequency 200KHz and 500KHz are optional;
- Subdivision setting (within 200~51200);
- With protections such as overcurrent, overvoltage and tracking error out of tolerance;
- Six-digit digital tube display, easy to set parameters and monitor the running status of the motor, etc.
Pre-sales service:
- According to customer’s requirements, we design, produce and sell products;
- Complete matching products for choice, we provide customers with various convenient service, OEM service.
In sales service:
- Accurately provide product knowledge to customers; patiently help customers select product models; skillfully carry out product operation demonstration; improve sales efficiency and save customers` shopping time; carry out supporting service work of sales to facilitate customers.
After sales service:
- delivery service; operation service; "Three Guarantees" service; user return visit tracking service; handling customer complaints and positive response service.
