Şişecam - Temperable Solar Control Low-E Glass
From Architectural Glass
Şişecam Temperable Solar Control Low-E Glass is Şişecam Flat Glass’ heat and solar control glass. Şişecam Temperable Solar Control Low-E Glass is Şişecam Flat Glass’ heat and solar control glass. Insulating Glass Unit (IGU) manufactured with Şişecam Solar Control Low-E Glass reduces heat loss from windows by 50% compared to ordinary IGU. Therefore effective heat insulation in winter is provided and heating expenses are reduced. It also decreases solar energy transmission by 40-65% compared to ordinary IGU. Therefore it keeps cooler in summer and cooling expenses are reduced. Tempered heat and solar control glass is approximately 5 times more durable than annealed heat and solar control glass. Colors: Besides applied on clear float glass, temperable Solar Control Low-E coating can also be applied on green, gray, bronze and blue body tinted glass on demand.
Advantages
- The coating provides heat and solar control properties at the same time.
- Heating and cooling expenses are reduced.
- Provides alternative solutions to projects with its different performance choices.
- In accordance with architectural trends, provides solutions to safety requirements which is rising in line with expansion of the glass surface area and increase in glass thickness. It eliminates the risk of injury by dividing into small pieces which are not sharp, when breaks.
- Reduces condensation on glass surface.
- In winter cold spots, in summer hot spots by windows are eliminated and heat inside the room is radiated equally.
Applications
Şişecam Temperable Solar Control Low-E Glass provides comfortable living areas to end users with its thermal insulation and solar control property; also provides best solutions for safety requirements when it is tempered.
- Neutral 60/28; ensures to benefit from maximum daylight in projects such as residences, offices, hotels, hospitals and education complexes where high light transmisson, maximum solar control, low reflection and neutral effect on façade are required; also reduces solar energy transmission by compared to ordinary Insulating Glass Unit and decreases cooling expenses.
- Neutral 70/37; provides solutions for residences, villas and store front glazing where transparency and low reflection are required.
- Neutral 58/32; provides solutions for residences, offices and commercial buildings where high light transmission and efficient solar control are necessary.
- Neutral 51/28; is preferred in offices, hospitals and hotels where optimum light transmission, maximum solar control and greenish color effect on façade are required.
- Neutral 50/27; is preferred in offices, hospitals and hotels where optimum light transmission, maximum solar control and bluish color effect on façade are required.
- Neutral 62/44; provides solutions for residences and education complexes where high light transmission is needed.
- Neutral 50/33; provides solutions for green building certified (LEED and BREEAM) projects such as offices, hotels and hospitals where optimum daylight transmission and efficient solar control are necessary.
- Neutral 41/27; is preferred in skylights or warm climate areas where daylight control and more efficient solar protection are required.
- Deep Blue 40/28; provides solutions for skylights and residence projects where daylight control, more efficient solar control and blue color effect on façade are required.
Technical Specification
Şişecam Temperable Solar Control Low-E Glass is manufactured by depositing multi-layered metal/metal oxides on float glass through 'magnetically enhanced vacuum sputtering' technology.
“Daylight” and “Solar Energy” properties are calculated with “TNO Science and Industry - WIS 3.01” program using spectral measurements in compliance with EN 410.
“U-value” is calculated with “TNO Science and Industry - WIS 3.01” program according to EN 673. The emissivity measurements used for calculations are in compliance with EN 673 (Annex A) and EN 12898.
Thermal stresses or building codes may require the use of heat-treated glass. This document is not an evaluation of the risk of glass breakage from thermal stresses. Please contact Şişecam Flat Glass to ensure the correct form of glass to be supplied for the structure.
Specifications, technical and other data are based on information available at the time of preparation of this document and are subject to change without notice.
Trakya Cam Sanayii A.Ş. cannot be held responsible for any deviation between the data introduced and the conditions on site. This document is only informative, in no way it implies an acceptance of the order by Trakya Cam Sanayii A.Ş.
Daylight Transmittance (%): The ratio of the visible spectrum (light) that is transmitted through glass.
Daylight Reflectance (outdoor) (%): The ratio of the visible spectrum (light) that is reflected outside by glass.
Solar Factor: The percentage of total solar radiant heat energy entering the room thorough the glass. The lower solar factor means better solar control.
Shading Coefficient: The ratio of solar factor of a particular glass type to the solar factor of 3 mm clear float glass, set in identical conditions. The lower shading coefficient means better solar control.
U value (W/m2K): A measure of the rate of heat loss of a building component. The lower U value means better heat control and more comfort in winter.
Quality
Şişecam Temperable Solar Control Low-E Glass is manufactıred an accordance with EN 1096 Glass in Building - Coated Glass.
