Beswick - Model QDC-101-I - Single Shut Off, Quick Disconnect - External Pin

SHARE

The QDC-101-E External Pin is part of Beswick USA's standard snap-type quick disconnect assembly designed for systems requiring a reliable and efficient disconnection mechanism. This specific model is compatible with both the single shut off QDC-101-I and the no shut off QDC-101-I-NS internal halves, providing flexibility in application choices. The QDC-101-E can handle a maximum pressure rating of 500 psig while connected, although caution is advised when disconnecting lines under pressure due to venting to the atmosphere. For safety, it is recommended that connecting or disconnecting operations be performed at a maximum pressure of 120 psig. Note that the actual pressure rating may vary depending on the tubing selection if barbed configurations are used. With an emphasis on seamless integration and robust performance, the QDC-101-E is ideal for applications requiring quick and dependable disconnect solutions.

Most popular related searches
connection sleeve

External half of our standard snap-type quick disconnect assembly.  This QDC-101-E series is compatible with both the single shut off QDC-101-I series and QDC-101-I-NS no shut off series internal quick disconnect halves.

Max Pressure Rating: 500 psig while connected.  Take caution when disconnecting lines under pressure since the external pin has no shut-off and will vent to atmosphere when disconnected.  Due to this, our recommended maximum pressure for connecting or disconnecting the assembly is 120 psig.*

*Note that the pressure rating of configurations using barbs will likely be limited by tubing selection.

  • Snap connection and releasing sleeve disconnection.
  • Compatible with both single shut off and no shut off internal QDC-101 connecting halves.
  • QDC-101-E & QDC-102-E must be paired with a QDC-101-I or QDC-101-I-NS half for a complete quick disconnect assembly.
  • The QDC-101-E series is NOT compatible with the QDC-101-DS double shut off series.
