ASI Doors - Model XP 2700 ISO-FLEX - Single Sliding Flexible Panel Cooler/Freezer Doors
FromASI Doors, Inc.
Durability and cost savings are engineered into every aspect of ASI Doors’ patent pending, cold storage door. From its flexible panel to its exclusive wall track guidance system, the XP Iso-Flex is designed to reduce downtime and repair costs, while increasing energy savings and productivity.
Most popular related searches
DOOR SIZES
- Minimum: 5`x 7`
- Maximum: 8` x 19` (Other sizes available - consult factory)
PANEL CONSTRUCTION
- Sealed design
- Thermoplastic outer shell
- Polyurethane perimeter panel edge
- XLPE foam
- 4" thick, R-17, thermoplastic panel construction
OPERATION
- Powered model has high speed electromechanical operator. (Open-Speeds up to 50′′/sec. - Close - up to 25"/sec)
- 115/230 volt AC, single phase, or 460 volt AC, 3-phase
- DC motor with clutchless / brakeless operation
- Encoded self-calibrating limit position
- Standard motor / encoder IP65 rated
- Remote HMI digital display with self-diagnostics, history function and fault indicators
PERFORMANCE FEATURES
- Torque sensing stop/reverse full height of door panels
- Header mounted control box with pre-wired remote digital display
- Pre-wired motor and encoder
- LED indicators in control box for door status
OPTIONS
- Manual operation
- Stainless steel header construction
POWER DOORS ONLY:
- Actuators: Pull cord, push button, photo eye, radio control, loop detector, motion detector
- Pre-announce to close kit (LED light bar)
- Standard operation – (2) pull cords or (2) push buttons with time delay close
- Standard operation - activate open time delay close
WARRANTY
- Two year limited warranty on all components
