Dongguan Gemwell Machinery Co., Ltd.
Gemwell - Single Twist Pairing Machine
Communication cables with excellent electrical characteristics, should be match the stringent requirements for high-bandwidth system, such as USB, HDMI, DP, MHL, DVI, LAN cables etc.
- Single Twist Pairing Machine Description:
- Motorized Pay off DIN 400-500
- Longitudinal taping head
- Single twist pairing machine DIN 400-500
- PLC control system with color touch screen
Single Twist Pairing Machine Advanced function (Optional):
- Back-twist payoff
- HMI + PLC control system, twisting pitch, production, line speed set on touch screen, alarm and recipe system, easy operation.
- High productivity, horizontal type ensure run steady while in high rotating speed, speed up to 1100RPM, production efficiency is 2 times than vertical type.
- Pitch accurate, changed mechanically, so pitch can be constant when speed accelerating or decelerating.
- Self-traversing, traversing and bobbin-holding devices from one complete unit. Traversing unit moves on railway guides via motor, superior quality for twisted cable electrical performance.
