RediHaul - Model FSL14E-102 - Skid Loader
Main Frame: 5" x6.7# Channel, high strength structural steel. Bed Crossmembers: 3" x 2.9# Jr. I-Beam , high strength structural steel. Tongue: A-Frame 5 " x6.7# Channel, high strength structural steel & 6" x 3" x 3/16" Rec tube, high strength structural steel. Axles: 2 - 6,000#; 3" O.D. Beam, .25 wall; inner bearing, 1.75 I.D.; outer bearing, 1.25 I.D.. Brakes: 12" x 2" Electric Brakes on all wheels, E-Z Lube Hubs.
Most popular related searches
- Suspension: Slipper spring with equalizer, 5 leaf spring, 2" wide per axle per side, 3,500# per side per axle
- Tires: 4 - ST225/75R X 15 "D" 2,150# each @ 60 PSI
- Wheels: 4 - 6 x 15 single wheel, 4.27 pilot 6 on 5 1/2" bolt circle 2,600# each
- Decking: 2" Nominal Oak Floor Bolted Down
- Deck Dimensions: 17` Long x 6` 9 " Wide (81" Between Fenders, 102 O.A.W.)
- Includes 14` Flat Deck & 3` Beavertail
- Deck Height: 24"
- Coupler: 2 5/16" Adjustable Height Ball Coupler (2 1/2" Pintle Eye Optional)
- Landing Jack: 7,000# Drop leg
- Ramps: 2 - Adjustable 48" ramps
- Wiring: Sealed modular wiring, 7 Pole Flat Prone Plug. Safety breakaway system with tow charger (battery optional)
- Lights: All D.O.T. required; sealed and shock mounted LED lights
- Extras: 3/8" x 36" Grade 70 safety chains with slip hook & safety latches
- G.V.W.R.: 9,990#
- Capacity: 7,410#
- 81" Wide (Between Fenders)
- 17` Long (14` Flat + 3` Beavertail)
- 2- 4` x 15 1/4" Wide Adjustable Ramps (FSL14 & FSL14H)
- 2- 5` x 15 1/4" Wide Adjustable Ramps (FSL14HD)
- 2 5/16" Adjustable Height Ball Coupler
- 7,000# Drop Leg Jack (FSL14 & FSL14H)
- Safety Chains with Snap Hooks
- Sealed Modular Wiring System
- Sealed and Shock Mounted LED Lights
- Safety Breakaway System with Battery
- Electric Brakes with E-Z lube hubs
- 4- Tie Down Rings ("D" Rings) 2 per side
- 12,000# Drop Leg Jack (FSL14HD)
- Hydraulic Surge Brakes
- Gooseneck Hitch (Electric Brakes only)
- Full Width 2 Piece Expanded Metal Ramp (in lieu of standard)
- Oak Inlay Ramps (in lieu of standard)
- Spring Assist for Ramps
- 5` Long Ramps (in lieu of 4` Ramps FSL14 & FSL14H)
- Expanded Metal on Bottom of Tongue
- Tapered Edge on End of Ramps
- Tapered Edge on 2 Piece Full Width Ramp
