Valgo - Model HR - Slitting Line
We manufacturing also HR slitting line for 1.5 to max. 10mm thickness of HR coil and width 800 mm to 2500mm and up to 30m/min line speed.
Most popular related searches
- Coil-car
- Uncoiler
- Startiner
- Loop I
- Screap winder or chopper (as per you’re requirement)
- Loop II
- Tension unit
- Feeder unit
- Slitter hear
- Rewinder unit with assisting support
- Exit coil car
- With all hydralic system
- And all electric systems etc.
We provide you electric system with computer display with all controlled with plc (as per your requirement like abb, simens, etc.) For metal like stainless steel high, carbon steel, galvanized steel, aluminum etc.,
We also design customized and special purpose slitting line as per your requirement.
| MODEL | PROCESSING METERIAL | PROCESSING SHEET THK | COIL WIDTH | COIL WEIGHT | COIL OD | CUTTING ACCURACY | LINE SPEED |
| VMSL – 4×1650 | Δs≤230n/mm2,hot-rolled coil | 1.5~4.0mm | Max 1650mm | ≤25t | Φ610mm~φ820mm | ±1.5mm | 0~30m/min |
| VMSL – 6×2000 | 1.5~6.0mm | Max 2000mm | ≤30t | Φ610mm~φ820mm | |||
| VMSL – 8×2500 | 4.0~8.0mm | Max 2500mm | ≤35t | Φ610mm~φ820mm |
