Solar PSTModel PST250 -Solar Collectors

SHARE

The Thermodynamic Solar Collectors provide hot sanitary water up to 50ºC, day and night, with rain, wind and in absence of sun. At present there is no superior technology on the market than this, which can provide an energy saving of up to 80% all year round. The Solar PST technology represents the main water heating system either in summer and in winter time with no need of a backup system as long as the external temperature is above 0ºC. Maintenance for the equipment is almost non -existent providing maximum safety and security. The domestic systems are comprised of cylinders from 250L up to 450L which are supplied in kits for an easy and safe installation, 250L enamel PST250V and 450L inox with 2 panels PST450IS. Solar PST systems are compatible with any water heating system as the Solar PST cylinders can be supplied with an extra coil upon request. (PST250IM and PST450ISM).

Most popular related searches
  • Thermodynamic Solar Collector.
  • Cylinder of 250L.
  • Thermodynamic Block (compressor included).
  • Inmersion Heater Backup.
  • Gasket with control panel included.
  • Brackets kit made of aluminium.
  • Security valve.
  • Reduction pressure valve
  • Neoprene joint
  • Stainless steel bolt kit
SPECIFICATIONS   PST250V/IM
Volume L 250
Thermal power (Average/Max) W 1690 - 2900
Absorbed power (Average/Max)     W 390 - 550
Temperature (Default) ºC 52
Temperature Max ºC 65
Cant. Máx útil agua a 40ºC L 317 / 308
Maximum working pressure bar 6
Number od collectors   1
Line of liquid Pol 01-Apr
Line of aspiration Pol. 03-Aug
Electrical support power W 1500
Dry weight Kg. 83 / 69
Power feed V / Hz      230/50
