Şişecam - Solar Thermal Collector Glass
From Solar Glass Products
Şişecam Glass For Solar Thermal Collector is Şişecam Flat Glass’ low iron, patterned, tempered glass used in solar thermal collectors. Glass For Solar Thermal Collector is an integral and important component of thermal collectors which collects heat by absorbing sunlight to produce hot water. The top layer of solar thermal collectors is made of glass, which protects the internal parts of solar energy systems from environmental effects. Also, its high heat transfer coefficient directly affects the efficiency of solar thermal collectors. Low iron, patterned glass that come in Sandy and Prism patterns reduce heat losses and provide maximum efficiency in terms of performance of solar thermal collectors. Şişecam Flat Glass also manufactures sandy-textured patterned glass in size of 190 x 90 cm to meet the needs of patterned glass for solar thermal collectors.
Quality
- EN 572-5 Glass for buildings - Basic soda lime silicate glass products - Section 5: Patterned glass.
- EN 12150-1 European Norms for Thermally Toughened Soda Lime Silicate Safety Glass
Technical Specifications
Şişecam Glass For Solar Thermal Collector is produced in 3.2 mm and 4 mm thicknesses and in Prism and Sandy patterns as cover glass of thermal collectors.
Dimensions (mm) :
- Tempered : 750x1500 mm; 1500x3000 mm
- Edge working : 750x1500 mm; 1500x2500 mm
- Raw Glass (Low Iron Patterned Glass) : 1000x2200 mm; 2400x3300 mm
The transmission levels of the glasses are measured and certificated by the company of SPF (Solartchnik Prüfung Forschung) in a regular period of the time.
Packing
Different types of packaging are available to suit the needs of the customers for the transportation of solar panel glass.
Basically, the packaging alternatives consist of horizontal wooden case, vertical wooden case, metal L racks, end cap type wooden case.
Şişecam Flat Glass provides exceptional service to best meet the needs of its customers by providing packaging alternatives according to requirements, and takes care to use recyclable packaging in order to maintain and implement its environmental awareness.
The material to be used between glass sheets are also determined according to the requirements of the customers, with paper and powder packaging alternatives available.
