KPA Unicon - Model WF/SF & WT/ST -Solid-Liquid Fuel Boiler Plant

Engineered and built in Finland
Unicon fire tube boiler plants are designed and manufactured in Finland. We can assemble a boiler plant on site or build and transport a modular-type plant. Our modular design structure minimizes costs without compromising quality. In combination plants, water and steam boilers can be installed in the same building. Our boiler design also minimizes sediment build-up and it features a cleaning system for optimal boiler performance.

Module structure minimizes cost without compromising quality

Our boiler plants can be manufactured as module types. The modules are pre-assembled and tested at the workshop in Finland. The modules are dimensioned so that they can be transported by rail, sea  or road. At the site, the modules are installed side by side and the plant is ready for commissioning.  The module structure minimizes the delivery time of the plant.

Our plants are known for their efficiency. We hold ourselves to the same standard
We’ll work with you and help you determine the right solution for your unique situation, finding the ideal balance between fuel costs and plant efficiency. And when we install a plant, minimizing downtime for our customers is more than a priority, it’s a necessity. We want our solutions to be cost-effective for your business. That’s the only way the world’s transition to clean energy can become a reality.

The best of both worlds – for a cleaner, healthier world
Unicon boiler plants are a clean energy solution that is more cost-effective and more environmentally sound. They turn waste gases and other fuels into useful electricity, steam or hot water and they significantly reduce emissions in the process – and that’s a far cry from just releasing the gases into the air.

We’ll help you choose the best Unicon boiler for your needs.

• WF/SF Fire Tube Boilers
• WF: Fire tube boiler for peak load district heating or for process hot water production
• SF: Fire tube boiler for process steam production
• WT/ST Water Tube Boilers
• WT: Water tube boiler for peak load district heating or for process hot water production
• ST: Water tube boiler for process and power-generating industries for steam production

Unicon Boiler Highlights:

Reduced emissions in accordance with strict European BAT emission limits
On-site assembly or modular design and delivery option
In combination plants water and steam boilers can be placed in the same building

MODEL: UNICON WF - Hot water boiler

• Capacity: 5 - 300 MW
• Boiler: Three-pass fire tube boiler
• Boiler size: 1 - 40 MW
• Pressure (max): 20 bar
• Temperature: 205 °C
• Fuel: Natural gas, light and heavy fuel oil
• Operating efficiency: 90 - 95 %
• Burner equipment: One or two automatic modulating burners per boiler

MODEL: UNICON SF - Steam boiler

• Capacity: 7 - 300 t/h
• Boiler: Three-pass fire tube boiler
• Boiler size: 1 - 40 MW
• Pressure (max): 20 bar
• Temperature: 300 °C
• Fuel: Natural gas, light and heavy fuel oil
• Operating efficiency: 90 - 95 %
• Burner equipment: One or two automatic modulating burners per boiler

MODEL: UNICON WT

• Capacity: 20 - 500 MW
• Boiler: Natural circulation water tube boiler
• Boiler size: 20 - 120 MW
• Pressure (max): 25 bar
• Temperature: 205 °C
• Fuel: Natural gas, light and heavy fuel oil
• Operating efficiency: 90 - 95 %
• Burner equipment: One or two automatic modulating burners per boiler

MODEL: UNICON ST

• Capacity: 30 - 600 t/h
• Boiler: Natural circulation water tube boiler
• Boiler size: 30 - 100 MW
• Pressure (max): 50 bar
• Temperature: 480 °C
• Fuel: Natural gas, light and heavy fuel oil
• Operating efficiency: 90 - 95 %
• Burner equipment: One or two automatic modulating burners per boiler
