These cables can be fixed on cable trays, within conduits or fixed to walls. They also can be buried directly with extra mechanical protection.
Cross sections 1,5 - 2,5 and 4 mm² have to be of class 2 flexiblility, if the cable is connected to equipment subject to vibration.
Construction characteristics
Conductor flexibility: Stranded class 2
Conductor material: Aluminum
Insulation: XLPE (chemical)
Outer sheath: PVC
Sheath colour: Black
Conductor shape: Circular
With smaller neutral conductor: No
Dimensional characteristics
Conductor cross-section: 150 mm2
Number of cores: 1
Approximate weight: 1472 kg/km
Ground conductor cross-section:- mm²
Maximum outer diameter: 14.1 mm
Electrical characteristics
Rated Voltage Uo/U (Um): 0,6/1 kV
Permissible current rating in open air: 344 A
Permissible current rating when buried: 316 A
Voltage drop, single phase: 0.47 V/A.km
Mechanical characteristics
Mechanical resistance to impacts: Good
Cable flexibility: Rigid
Usage characteristics
Max. conductor temperature in service: 85 °C
Short-circuit max. conductor temperature: 250 °C
Length: 1000 m
Operating temperature, range: -10 ... 60 °C
Packaging: Drum
Flame retardant: C2, NF C 32-070
Weather resistance: Very good
Chemical resistance: Accidental
Bending factor when laying: 6 (xD)
